Featuring full hydraulic operation, it includes a back pressure valve, high-pressure hydraulic filter, two-way balance valves, and special hydraulic lines for plateau conditions.
This wrecker has the functions of lifting, pulling, lifting, etc. It is convenient, quick, good-looking, safe and reliable. This truck wrecker is widely used in highways, public security traffic police, airports, terminals, auto repair industry and highway companies, etc.
Wrecker truck equipped with lifting winch device and wheel bracket which can lift, towing, back load and transport.Widely used in road, police traffic, airports, docks, auto repair company, industry and highway departments, timely, fast clean-up accident, failure, illegal and other vehicles.
Road wrecker is used for safety salvage of vehicles subject to city road, suburb way, highway, airport and bridge road. It is suitable for medium and small-sized cargos, cars and other special vehicles, which are allowed within the technical parameters of this kind
The tow wrecker is called the road wrecker, also known as road rescue vehicle. It has many functions such as lifting, pulling and lifting traction.
Vehicle Type: Sewage tank truck
Number of Units: 4Superstructure Configuration: 12000L water tank (6.0mm carbon steel), Single compartment, DN75 inlet, DN100 outlet, SK-12 vacuum pump. Top overflow valve, pipeline equipped with large pressure gauge, tank top with rotatable manure suction frame, 6 sets of 5-meter DN100 suction pipes with complete connecting accessories and inlet filters, equipped with 2 quick-opening valves, and a threaded connecting joint at the rear of the valve body. Equipped with an automatic water inlet valve mechanism to prevent overflow and a fecal viewing window. The top of the tank body is equipped with a 500mm diameter manhole, equipped with a hole cover and sealing ring, equipped with anti-slip walkways and steel pipe ladders, and storage boxes on both sides of the tank body for storing pipes and accessories.
The FAW RHD 12CBM Sewage Suction Truck is a high-capacity, professional sanitation vehicle designed for efficient septic sludge, wastewater, and manure removal in municipal, agricultural, and industrial applications. Built on the robust FAW JK6 4×2 chassis with right-hand drive, it is powered by the CA6DL1-26 diesel engine (260hp) and fitted with 10.00R20 tires, delivering strong torque and reliable performance even under heavy-duty conditions.
The superstructure features a 12,000-liter single-compartment tank made of 6.0mm-thick carbon steel, ensuring durability and corrosion resistance. It is equipped with a powerful SK-12 vacuum pump, enabling rapid suction through a DN75 inlet and discharge via a DN100 outlet. The system includes a top-mounted overflow valve, large pressure gauge, and an automatic water inlet valve to prevent overfilling, along with a fecal viewing window for real-time monitoring.
For operational flexibility, the tank top is fitted with a rotatable manure suction frame and a 500mm-diameter manhole with a sealed cover. The truck comes with six 5-meter DN100 suction hoses, complete with connectors, filters, two quick-opening valves, and a threaded rear joint for secure coupling. Safety and accessibility are enhanced by anti-slip walkways, steel pipe ladders, and side-mounted storage boxes for organized tool and hose stowage.
Combining high suction capacity, smart safety features, and rugged construction, the FAW RHD 12CBM Sewage Suction Truck is an ideal solution for sewage treatment plants, sanitation departments, and rural sanitation programs requiring dependable, large-volume waste extraction and transport.
