Vehicle Type: Compactor Garbage Truck

Number of Units: 1

Export Country: Jamaica

Chassis Configuration: HOWO,6*4 type,Right hand driving,WD615.47 engine（371hp）

Superstructure Configuration: 23CBM garbage hopper，6mm Q345 steel，Robot automatic welding process, Boli cylinder, Changyuan double oil pump, Changyuan multi-way valve, full hydraulic operation, with back pressure valve, hydraulic oil high pressure filter, two-way balance valve, special hydraulic oil pipe for plateau , CAN electronic control system, (with one-key operation and manual operation two control modes) a total of three operation boxes (operable inside the cab and on both sides of the rear tail), a light, a sewage tank on the side of the girder, There is a sewage tank at the bottom of the filler to ensure that there is no leakage of sewage in the tank. The tail is equipped with a swing arm turning mechanism and a GPS system is installed.

Garbage Compactor truck is the machinery of choice for door to door collection of waste. The collected waste is simultaneously compacted and eventually transported to the dumping site. Compactors have multiple benefits over conventional waste trolleys namely: Waste is covered and there is no chance of "spillage" of waste during transportation. Continuous compaction allows more waste to be stuffed onto a truck which reduces the number of round trips to the dumping site. This results in significant fuel saving. Waste collected inside the compactor is pushed out of the container through a hydraulically powered Ejection Plate. Two men are required to perform the entire functionality of the compactor namely, driver and operator.

Collection way of garbage compactor truck is simple, can eliminate the second pollution, compression ratio high,large loading capacity,high automation operation, good economy, double insurance system, high efficiency.There are three kinds of mechanism options available to the customer,barrel turnover mechanism,panel turnover mechanism and tipping mechanism.By the user of hydraulics,the barrel is locked during the overturning process.which is very safe and realiable.

Operation Automation: With the computer control system, the driver is required to operate all the loading and unloading operations. Two operation modes, automatic and semi-automatic, can be set up, which not only reduces the labor intensity of sanitation workers, but also greatly improves the working environment.

Good economy: When the special equipment works, the computer control system automatically controls the throttle.
