This wrecker has the functions of lifting, pulling, lifting, etc. It is convenient, quick, good-looking, safe and reliable. This truck wrecker is widely used in highways, public security traffic police, airports, terminals, auto repair industry and highway companies, etc.
Wrecker truck equipped with lifting winch device and wheel bracket which can lift, towing, back load and transport.Widely used in road, police traffic, airports, docks, auto repair company, industry and highway departments, timely, fast clean-up accident, failure, illegal and other vehicles.
Road wrecker is used for safety salvage of vehicles subject to city road, suburb way, highway, airport and bridge road. It is suitable for medium and small-sized cargos, cars and other special vehicles, which are allowed within the technical parameters of this kind
The tow wrecker is called the road wrecker, also known as road rescue vehicle. It has many functions such as lifting, pulling and lifting traction.
The INT series is out integrated line of tow trucks commonly called wreckers. We have a wide range of products with 6 different models ranging for the small 3 ton to the massive 60 ton with a 3 stage boom.
Superstructure Configuration: 6CBM garbage hopper，4mm Q345 steel，Robot automatic welding process, full hydraulic operation, with back pressure valve, hydraulic oil high pressure filter, two-way balance valve, special hydraulic oil pipe for plateau , CAN electronic control system, (with one-key operation and manual operation two control modes) a total of three operation boxes (operable inside the cab and on both sides of the rear tail), a light, a sewage tank on the side of the girder, There is a sewage tank at the bottom of the filler to ensure that there is no leakage of sewage in the tank.
The dustbin is made of Q345 high-strength steel plate.
The side panel adopts one-piece molding process, with arc shape, beautiful appearance, firm structure, light weight and good force.
The push shovel is composed of rectangular tube frame and Q345 high-strength plate, with a streamlined push surface, not only light in structure, but also smooth and thorough in discharging materials.
The special M-type double-layer silicone sealing strip is installed on the joint surface of the dustbin and the filler, and is compressed and sealed by a hydraulic locking device, which has good sealing performance; The lower part is designed with a water receiving tank with a special structure, double protection, effectively prevents sewage from dripping, and prevents secondary pollution.
An emergency stop button is set to stop the garbage compaction device in any state or position, ensuring the safety of operators
and equipment.
It has two modes of operation, automatic and manual, and the operation control boxes are respectively installed in the cab and on both sides of the rear of the vehicle, which is very convenient to use and operate. (A wireless remote control device can be installed)
During operation, the engine output power is automatically controlled by the electronic throttle controller to ensure that the engine can automatically select the acceleration and idling states in each operating state of the garbage truck, avoiding power loss and system heating, reducing fuel consumption and good economy.
The lifting cylinder is equipped with a smooth valve to prevent the filler from falling when the oil pipe suddenly bursts, and a
safety brace is provided to ensure the safety of personnel during maintenance.
