This wrecker has the functions of lifting, pulling, lifting, etc. It is convenient, quick, good-looking, safe and reliable. This truck wrecker is widely used in highways, public security traffic police, airports, terminals, auto repair industry and highway companies, etc.
Wrecker truck equipped with lifting winch device and wheel bracket which can lift, towing, back load and transport.Widely used in road, police traffic, airports, docks, auto repair company, industry and highway departments, timely, fast clean-up accident, failure, illegal and other vehicles.
Road wrecker is used for safety salvage of vehicles subject to city road, suburb way, highway, airport and bridge road. It is suitable for medium and small-sized cargos, cars and other special vehicles, which are allowed within the technical parameters of this kind
The tow wrecker is called the road wrecker, also known as road rescue vehicle. It has many functions such as lifting, pulling and lifting traction.
The INT series is out integrated line of tow trucks commonly called wreckers. We have a wide range of products with 6 different models ranging for the small 3 ton to the massive 60 ton with a 3 stage boom.
Design a tow truck body that perfectly suited to client's existing chassis, ensuring optimal compatibility and performance. Extensive drawings and blueprints were produced, reviewed, and refined in close collaboration with the customer to guarantee that every aspect of the design met their expectations.
Brand:
CLVEHICLES.COMModel No.:
CL5251TSMinimum Order Quantity:
1 UnitPrice:
USD41200Payment Terms:
T/T, L/C, Western UnionDelivery Time:
25~35 days after we get the depositShipping:
Ro-Ro/Bulk cargo/Container shipment / SKD / CKD / etc25 tonheavy duty integrated wrecker recovery truck superstructure
The tow truck wrecker is also called road wrecker truck, tow truck wrecker, wrecker towing truck, wrecker, road block removal truck, breakdown truck, tow truck, recovery truck, etc.
Our tow truck consists of the chassis, hoisting equipment,truck tow hook, tow truck winch, tow truck wheel lift, hydraulic system, electric control system, truck body and the tool boxes.
Quick Details
| Chassis Brand | - |
|
Max Lifting Capacity of Under Lift |
25000kg |
|
Max towing capacity of Under Lift |
60000kg |
|
Max Pulling Force of Winch |
15000kg*2 |
|
Max Lifting Capacity of Boom |
25000kg |
Applications
Wrecker tow truck is used to move disabled, improperly parked, impounded, or otherwise indisposed motor vehicles. This may involve recovering a vehicle damaged in an accident, returning one to a drivable surface in a mishap or inclement weather, or towing or transporting one via flatbed to a repair shop or other location.
|
|
|
|
A pair of training wheels makes towing working easily when wheels are damaged |
Extra Strength Winch with 21 meters steel cable |
|
|
|
|
Manual joystick with instructions on side body of the truck makes control work easily |
The tire belt keep car stability on wrecker truck |
Product Details
Customer Services
Pre sale service
--- Technical communication with engineer
--- Factory and workshop visit
--- Making design drawings
After Sale Service
--- Overseas installation & commissioning
--- Overseas and spare parts support
--- Technical and spare parts support
Truck
According to your request, choose good chassis and refit it to truck.
Upper Body
design function parts.
Customization
Spare Parts
on trucks as tank and box.
Supply only upper body without chassis. According to your chassis drawing,
Communicate with engineer,making design drawings and produce customized products.
Supply all kinds of spare parts on chassis and upper body,replace main parts
Product Parameters
|
Superstructure |
Max under-pulling capacity |
>=60000(kg) |
|
|
Underlift structure |
Towing capacity |
25000(kg) |
|
|
Fully extended capacity |
9500(kg) |
||
|
Retracted length |
1460(mm) |
||
|
Extended length |
3599(mm) |
||
|
Working angle |
-7 ~ +7 (゜) |
||
|
Folded angle unload |
-7 ~ +93 (゜) |
||
|
Boom structure |
Extracted lifting capacity |
25000(kg) |
|
|
Extended lifting capacity |
8000(kg) |
||
|
Extracted boom length |
5170(mm) |
||
|
Extended boom length |
8470(mm) |
||
|
Max lifting height |
6500(mm) |
||
|
Working angle |
5.0~33(゜) |
||
|
Winch |
Quantity |
2 |
|
|
Max. pulling power |
15000kg *2 |
||
|
Length of steel cable |
60m *2 |
||
|
Diameter of the cable |
Φ22 |
||
|
Min. speed of winch |
5 (m/min) |
||
|
Hydraulic outriggers |
Qty |
2 |
|
Wrecker truck basically is refitted from the loading goods second class chassis, according to the wrecker truck's structure, it can bedivided into tow, loading, lifting, rescue (single arm type and arms type) wrecker truck.
Wrecker truck, full name is road wrecker truck, is also called road rescue wrecker truck or towing truck. It has multiple functions such as lifting, pulled and lift traction. Wrecker truck is mainly used in road, city of peccancy vehicles and rescue, etc.
Wrecker truck basically is refitted from the loading goods second class chassis, according to the wrecker truck's structure, it can be divided into towing, loading, lifting, rescue (single arm type and arms type) wrecker truck. It has multiple functions such as lifting, pulled and lift traction. Wrecker truck is mainly used in road, city of peccancy vehicles and rescue, etc.
The basic equipment includes automatic clamping arrangement for small truck, boom, winch, wheel lift devices, construction alarm, rear working lighting, box for washing hands, U shape device for holding tires, 5 sets supporting forks, supporting fork stand, 2 pcs chain and hook, accessory lightings assembly, imported hydraulic pressure components, multi parts compartment truck body, uniform control devices on both sides, etc.
The INT series is out integrated line of tow trucks commonly called wreckers. We have a wide range of products with 6 different models ranging for the small 3 ton to the massive 60 ton with a 3 stage boom.
The tow wrecker is called the road wrecker, also known as road rescue vehicle. It has many functions such as lifting, pulling and lifting traction.
