SHACMAN F3000 Euro2 12 wheeler construction waste Tipper Truck

This truck is economic and practical. With high strength property.



  • Brand:

    CLVEHICLES.COM
  • Model No.:

    CL3255JM384
  • Minimum Order Quantity:

    1 Unit
  • Price:

    USD 58000
  • Payment Terms:

    T/T, L/C, Western Union
  • Delivery Time:

    25~35 days after we get the deposit
  • Shipping:

    Ro-Ro/Bulk cargo/Container shipment / SKD / CKD / etc
  • Overview
  • Parameters

SHACMAN F3000 Euro2 12 wheeler construction waste Tipper Truck


F3000 dump truck is well suited for transporting large capacity of coal, sand, stone and other materials. It possesses the advantages of light weight, efficient transportation, safety, reliability, stable performance and simple operation. Shacman F3000 dump truck has a unique WEVB engine braking system which can improve the braking performance by more than 55% and allow users to transport materials without security worries.


Quick Details


Chassis Brand

SHACMAN

Payload Capacity

25ton-40ton

Material of Tank

carbon steel

Horsepower

380hp

Application

Construction project, heavy duty transportation


Applications



A transfer dump is a standard dump truck pulling a separate trailer with a movable cargo container, which can also be loaded with construction aggregate — gravel, sand, asphalt, klinkers, snow, wood chips, triple mix, etc.




Competitive Advantages


Unique metal support ring welded structure allowing good cylinder stability and high cylinder expanding resistance.

 High strengthen steel compartment.

New & modern cab with big space and more comfort, all electrical equipment are controlled by ECO, can be left or right side.

Driving axle has big loading capacity, each axle is good stability, high safety factor and ability to work under high level pressure


Product Details





Customer Services


Pre sale service

--- Technical communication with engineer
--- Factory and workshop visit
--- Making design drawings


After Sale Service
--- Overseas installation & commissioning
--- Overseas and spare parts support
--- Technical and spare parts support

Truck

According to your request, choose good chassis and refit it to truck.


Upper Body
Supply only upper body without chassis. According to your chassis drawing,

design function parts.


Customization
Communicate with engineer,making design drawings and produce customized products.


Spare Parts
Supply all kinds of spare parts on chassis and upper body,replace main parts

on trucks as tank and box.




Product Parameters



Vehicle Description

Vehicle model

Tipper truck

Overall dimensions (mm)

11000×2500×3700

GVW (t)

≤70

Fact loading capacity(t)

40-50

Curb weight (kg)

Appro×15000

Max. Speed (km/h)

75

Chassis Description

Chassis Model

SX3315 (F3000 series)

Cab

One and half row with four-point hydraulic suspension, Electric controlled automatic constant temperature air conditioning, Hydraulic main seat, Right hand drive

Color

Optional

Allowable person in cab

3

Wheel base (mm)

1800+3575+1400

Front/Rear track base (mm)

1900/1860

Front/Rear overhang (mm)

1520/2060

Main frame (mm)

850×300 (8+7)

Number of axles

4

Axle

Front axle

MAN 7.5T *2

Rear axle

MAN 16T *2

Traction system

8*4

Operation control system

Power steering

Braking system

Full air

Electric system (V)

24

Clutch

Ф430

Gear box + PTO

10JSD160 + QH50

Number of gears

10 speeds + 1 reverse

Fuel tank (L)

380

Tire specification

12.00R20

Tire quantity

12+1

Engine Description

Engine manufacture

CHINA WEICHAI ENGINE CO., LTD

Engine model

WP12.380E 32

Engine type

Water cooling, four stroke, brake with exhaust valve, direct injection, supercharged and mid-cooling

Emission standard

Euro 2

Exhaust (ml)

11596

Max. output power (kw)

280

Max. horse power (hp)

380

Rated speed (rpm)

2200

Max. torque/ speed (N.m / rpm)

1600 / 1300-1400

Up-parts Description

Tipper box dimension (mm)

7400×2300×1500

Tipper box type

Rectangle type with reinforcing rib

Material

Q345 carbon steel

Thickness of side/bottom plate (mm)

8/ 10

Door open way

Rear single open

Hydraulic ram for dump

Front set φ180mm

Dumping gear support

4

Rotating shaft

Through type

Working Condition:

1、Altitude: 0-4500m

2、Temperature: -350C~+450C

3、Relative humidity: 80%

4、Wind force: ≤8 degree
