ISUZU 98hp 6CBM compression waste compactor truck

Garbage trucks are widely used in sanitation, municipal, factory and mining enterprises, and residential areas where have a lot of garbage.

  • Brand:

    CLVEHICLES.COM
  • Model No.:

    CLW5040YSLJ3
  • Minimum Order Quantity:

    1 Unit
  • Price:

    USD25600
  • Payment Terms:

    T/T, L/C, Western Union
  • Delivery Time:

    25~35 days after we get the deposit
  • Shipping:

    Ro-Ro/Bulk cargo/Container shipment / SKD / CKD / etc
  • Overview
  • Parameters

ISUZU 100P 6cbm garbage container trash compactor truck


Garbage trucks are widely used in sanitation, municipal, factory and mining enterprises, and residential areas where have a lot of garbage. Garbage trucks are classified into compressed garbage trucks, swing arm type, dump type, sealed type, docking type, hook type arm type, and pull arm type garbage truck. Garbage trucks can carry multiple compartments in one vehicle, which can effectively prevent secondary pollution during the loading and unloading process. The modified part is separable from the original car chassis, which is easy to maintain and maintain the mobility and driving performance of the original car. Customers who have special requirements for garbage trucks please contact with us at any time. We can produce the trucks according to your requirements.

Quick Details



Chassis Brand ISUZU
Volume of Garbage Tank 6000L
Filling Cycle Time 50-60s/once

Hydraulic Pressure

16Mpa


Applications


The garbage compactor truck (garbage compacting truck) is used to collect, transport and clearing up wastes, advoiding the secondary pollution. Features of the garbage dump truck, one kind  of new environmental truck, are easy, effective, and enviromental.

Garbage compactor truck is widely used in sanitation organization, municipal administration, mining area, property area, residential area, and many other places where garbage is centralized.




Competitive Advantages



Product Details





Customer Services


Pre sale service

--- Technical communication with engineer
--- Factory and workshop visit
--- Making design drawings


After Sale Service
--- Overseas installation & commissioning
--- Overseas and spare parts support
--- Technical and spare parts support

Truck

According to your request, choose good chassis and refit it to truck.


Upper Body
Supply only upper body without chassis. According to your chassis drawing,

design function parts.


Customization
Communicate with engineer,making design drawings and produce customized products.


Spare Parts
Supply all kinds of spare parts on chassis and upper body,replace main parts

on trucks as tank and box.




Product Parameters



Truck Specification

Truck model

CLW5040YSLJ

Cab

Single row cab

Driving Type

4*2 Left hand driving

Max Speed (km/h)

115

Overall dimension(mm)

6865×1870×2200

GVW( kg)

8200

Mass in working order( kg)

2460

Wheelbase(mm)

3360

F/R track base(mm)

1569/1530

F/R overhang(mm)

1068/1997

Approach/Departure Angel

22/25

Tire

700R15

Clutch

Single-plate dry diaphragm spring clutch

Steering

Hydraulic steering with power assistance

Gear box

5-speed

Bridge

Front axle

2.0T

Rear axle

3.5T

Enging

Model

4JB1CN

Fuel Type

Diesel fuel

Type

Water-cooled four-stroke,, direct injection, turbocharged

Exhaust(ml)

2771

Max output power/rotate speed (hp /rpm )

98/3400

Braking  system

Service Brake

Compressed air brake

Park Brake

Spring energy

Auxiliary brake

engine exhaust brake

Eletric system

24v

Upper-Body  specification

Material of tank

material : Q235,Thickness :4(mm) side /4(mm) rear

dirty tank volume

6 m³

filler volume

500L

filing time(s)

8~10s

filling cycle time(s)

50~60s/once

Discharge type

Dumping

Time for dumping

30-40S

Hydraulic pressure

16mpa

Controlling way

Manualy and electrical control

Hydraulic pump

532 model

 1 set

Multi-way valve

DL-15B-6

 1 set

Flap cylinder

80/45-410*180

 2 set

Lifting cylinder

80/45-900*580

 2 set

Scraper cylinder

80/45-700*415

 2 set

Skateboard cylinder

90/50-980*670

 2 set

Push plate cylinder

YSTB-1180*2420

 1 set

The electromagnetic valve

UZCT-115/24V

 2 set
