Brand:
CLVEHICLES.COMModel No.:
CL5160JSQ6BLMinimum Order Quantity:
1 UnitPrice:
USD 46600Payment Terms:
T/T, L/C, Western UnionDelivery Time:
25~35 days after we get the depositShipping:
Ro-Ro/Bulk cargo/Container shipment / SKD / CKD / etcDONGFENG 4x4 RHD 10Ton Crane Truck
Compared special crane truck with crane, with a high speed, climbing ability characteristics.Enables fast movements, efficiency, energy saving.With a flexible, easy to operate, efficient, safe, and reliable.
Quick Details
|
Chassis Brand |
DONGFENG AWD |
|
Max.Lifting Capacity of Crane |
10TONS |
|
Basic boom length |
8.5m |
|
Fully extended boom length |
25m |
| Sections of boom | 4 |
Applications
For general cargo lifting and other special things like timber and brick by changing other equipment.
|
|
|
|
Main boom material is HG70 high strength steel |
Strengthened hydraulic telescopic horizontal leg |
|
|
|
|
Automatic recovery device for hook.Double speed winch for heavy duty crane. |
Multiple modes and position of operation are optional. |
Product Details
Customer Services
Pre sale service
--- Technical communication with engineer
--- Factory and workshop visit
--- Making design drawings
After Sale Service
--- Overseas installation & commissioning
--- Overseas and spare parts support
--- Technical and spare parts support
Truck
According to your request, choose good chassis and refit it to truck.
Upper Body
design function parts.
Customization
Spare Parts
on trucks as tank and box.
Supply only upper body without chassis. According to your chassis drawing,
Communicate with engineer,making design drawings and produce customized products.
Supply all kinds of spare parts on chassis and upper body,replace main parts
Product Parameters
|
TECHNICAL PARAMETER |
||
|
I. Chassis |
||
|
Basis |
Model |
CL5160JSQ6BL |
|
Driving |
4×4 Right-hand drive (RHD) |
|
|
Chassis |
DONGFENG manual reversible cab,manual window,driving cabin A/C,FM,USB,power steering |
|
|
Wheelbase |
4500 mm |
|
|
Max. Speed |
60 km/h |
|
|
Dimension |
11200×2520×3480 mm |
|
|
Cab capacity |
1 Driver & 1 Passenger |
|
|
Curb weight |
9550 kg |
|
|
Gross vehicle weight |
18000 kg |
|
|
Front/Rear overhang |
1285/2415 mm |
|
|
Front/Rear wheel track |
1820/1860mm |
|
|
Approach/Departure angle |
17/11 (°) |
|
|
Tire |
Front |
10.00R20 |
|
Rear |
10.00R20 |
|
|
Axle |
Front |
5000kg loading |
|
Rear |
13000kg loading |
|
|
Transmission |
Gearbox |
8-Speed with 2 Reverse(Manual) |
|
Steering gear |
Recirculating ball-type steering |
|
|
Brake |
Type |
Compressed Air brake |
|
Service |
Disc (front)/Drum (rear) brake |
|
|
Parking |
Central drum brake |
|
|
Auxiliary |
Vacuum booster |
|
|
Engine |
Type |
4 stroke, direct injection, water cooling |
|
Model |
Cummins B190-33 |
|
|
Max. Power |
140 kw (190 hp) |
|
|
Max. Torque |
640 N·m |
|
|
Bore×Stroke |
102×120 mm |
|
|
Displacement |
5.9 L |
|
|
No. of cylinder |
6 (in-line) |
|
|
Emission rating |
EURO-III |
|
|
II. Upper-body (super structure) |
||
|
Crane |
Max Lifting weight |
10000kg |
|
Basic boom length |
8.5m |
|
|
Fully extended boom length |
25m |
|
|
No. Of arms |
4(U-type) |
|
|
Main winch rope diameter |
12mm |
|
|
No.of winch |
2 |
|
|
No. Of hook |
2 |
|
|
Material |
BS700 High strengthen steel |
|
|
Rotate equipment |
1.3m internal gear turntable, two-stage planetary reducer |
|
|
Outriggers |
4 sets(Front 2 sets, rear 2 sets.Equipped with the safety lock) |
|
|
Crane
|
Rotate degree |
360 degree |
|
Other equipment: Load moment indicator Operation room |
||
Crane truck is grouped together as a means of transport.By the boom, lifting torque, frame, legs and other parts.Crane left and right operation can be both positive and negative 360-degree rotation, can also be full rotation.
Boom crane truck (also called knuckle crane truck,crane truck ,lorry mounted crane truck ,truck cargo with loader crane, articulated boom crane truck,crane mounted truck , boom crane truck ,truck with crane ,truck mounted crane,etc) is used to lift the cargo,load ,transport and unload heavy stuff.
A crane is a type of machine, generally equipped with a hoist rope, wire ropes or chains, and sheaves, that can be used both to lift and lower materials and to move them horizontally. It is mainly used for lifting heavy things and transporting them to other places.
Cranes are commonly employed in the transport industry for the loading and unloading of freight, in the construction industry for the movement of materials and in the manufacturing industry for the assembling of heavy equipment.
Truck mounted crane, is one of our main products,which is also named hydraulic truck crane, crane, mobile crane, truck mounted crane, lorry truck, lorry-mounted crane, lorry crane, truck with loading crane, truck cargo crane, derrick cargo truck, gantry crane.
Truck with crane is also named truck with loading crane.It widely used in municipal construction,Coal mine engineering ,landscaping , the other construction materials and other equipment hoisting and transportation.
